1) Capacitive press fingerprint identification;
2) 160 * 160 pixels, 8 bit resolution;
3) 508dpi resolution rate, 3D image quality;
4) High speed SPI interface;
5) Ultra low power consumption;
6) Manual wake-up function of host computer;
7) It supports black screen unlocking and 360 degree unlocking;
8) Power supply voltage: 2.7V ~ 3.6V;
9) IO voltage: 1.8 / 2.7V ~ 3.6V;
10) Support acyclic mode;
Parameter | Description | Value | Units |
Die size | Square | NA | um |
Package | LGA(中max) | 15.2 | mm |
| LGA(中min) | 14.6 | mm |
Size sensing array |
| 160*160 | pixels |
Pixel resolution | 8bit | 256 | levels |
Interface | Serial SPI+interrupt+Reset | 4+1+1 | Pins |
Supply voltage | VDD, typical | 2.7~3.6 | V |
IO voltage | VDD IO, typical | 1.8 | V |
Supply current | Idle | <3 | mA |
| Image capture | <10 | mA |
| Sleep Mode | <20(typical) | uA |
| Deep Sleep Mode | <10 | uA |
Clock frequency | Master Clock Dynamic Frequency | >SPI CLK | MHz |
| SPI CLK | <12 | MHz |
Operating temperature |
| -40~85 | ℃ |
Storage temperature |
| -40~125 | ℃ |
Spatial Resolution |
| 508 | DPI |
ESD | Air discharge | ±15 | KV |
Glass | Smarthome | 100 | um |
Glass | Phone and Computer | 175 | um |
